RAM-B-138-UN4U RAM® Finger-Grip™ Universal Holder with Drill Down Base
Features
* Universal holder with flexible rubber-coated fingers to provide a secure grip of your device
* Includes drill-down 2.5" round base and medium length, B size RAM® double socket arm
* RAM ball and socket technology allows for near-infinite adjustability
* Made of powder-coated, marine-grade aluminium, stainless steel components, and high-strength composite for durability and reliability in the most demanding environments
* Backed by a lifetime warranty
The mount is designed with a 1" (B Series) diameter patented rubber ball and socket system that has adjustment points at both ends of the double socket arm; this allows for almost infinite adjustment and perfect viewing angles. The included RAM patented design dampens shock and vibration, helping to extend the life of your device.
The Composite Universal Finger Grip Holder comes with (3 sets) of four flexible rubber coated fingers placed along sides to grip your device. The fingers open by squeezing the ends to open the small finger arms. The bottom of the cradle includes a back plate that adds support to the device being held by the mount. The perfect solution for a phone mount, car mount and can be used with several other phone accessories including Samsung accessories and LG accessories.
For a list of some compatible devices see part RAM-HOL-UN4U but they include many hand held radios, smaller phones, GPS and any other devices that fit within the following dimensions:
Height Dimensions: (The top and bottom plates can be removed for larger devices)
Minimum with Top and Bottom Plates: 133mm
Maximum with Top and Bottom Plates: 152mm
Spine Plate Dimensions:
76mm Width x 76mm Height
Using Short Arm Side Clamps:
Maximum Depth: 19mm
Minimum Width: 31mm
Maximum Width: 76mm
Using Medium Arm Side Clamps:
Maximum Depth: 31mm
Minimum Width: 38mm
Maximum Width: 88mm
Using Long Arm Side Clamps:
Maximum Depth: 40mm
Minimum Width: 57mm
Maximum Width: 88mm
Round Plate Diameter
63.5mm
Round Plate Hole Patterns:
4-Hole AMPS:
1.181" x 1.496" (30mm x 38mm)
3-Hole AMPS 120- Degree
1.812” (46.0mm)
Arm Dimensions:
Overall Length:
94mm (3.69")
Socket-To-Socket Length:
76mm (3")
Overall Length:
127.8mm (5.03")
YouTube:
https://www.youtube.com/watch?v=4erFr6qwKEY&t=23s
https://www.youtube.com/watch?v=EC-bdR3KAww
https://youtu.be/NoHTwEC_87Y
https://www.youtube.com/watch?v=b_TtvLYShlw
Components
RAM-HOL-UN4U UNIVERSAL PLASTIC ATV HOLDER
RAM-B-201U DOUBLE SOCKET ARM FOR 1" BALL
RAM-B-238U 62 X 33mm DIAMOND BASE W/ 1 BALL
RAM-B-202U 62mm DIA.BASE WITH 1" BALL
