RAM GDS Modular Charger 10-30V with 90-Degree DC Cable

RAM-GDS-CHARGE-M55-V7B1U GDS® 10-30V Hardwire Charger, 90-Degree DC Cable

RAM-GDS-CHARGE-M55-V7B1U is a GDS® hardwire charger with a 90-degree DC output cable, providing power to any GDS® vehicle solution from a 10-30V DC source. Unplug and swap in a new charger when upgrading devices, with no rewiring needed.

Key Features

• 90-degree DC output cable for a lower-profile install.
• Quick disconnect: connect any USB Type-A charging cable.
• 3 year warranty.

Works With

Any 5V device with a current requirement of 2.5A or less.

Dimensions & Specifications

• Input voltage: 10-30V DC
• Output voltage: 5-9V DC (5V via USB 2.0 BC1.2/DCP mode, 9V via AFC and QC 2.0)
• Output current: 2.5A max
• Input connector: 90° DC plug
• Input cable length: 1.2m
• Output cable length: 0.2m
• Operating temperature: -10°C to +70°C
• Storage temperature: -40°C to +70°C
• Compliance: over voltage, short circuit and reverse polarity protection, SAE J-1113-5 load dump, RoHS, WEEE, CE, e-Mark, RCM, FCC
• Weight: 177g (0.39lb)
• Warranty: 3 years
