RAM Mounts

RAM GDS Modular Hardwire Charger with 90-Degree DC Cable

RAM GDS Modular Hardwire Charger with 90-Degree DC Cable

SKU:RAM-GDS-CHARGE-M55-V8BU

Regular price $79.28 NZD
Regular price Sale price $79.28 NZD
Sale Sold out
Tax included. Shipping calculated at checkout.
View full details

RAM-GDS-CHARGE-M55-V8BU RAM GDS® Modular 30V - 64V Hardwire Charger with 90-Degree DC Cable


Features

* Hardwire charger includes USB Type-A female connector
* Includes 90-Degree DC Cable
* When upgrading devices, avoid rewiring by unplugging power connector and attaching new charger components
* Part of the GDS® Ecosystem™ to keep devices protected, connected, and charged in nearly any application
* Backed by a 3-year warranty




The GDS® Modular Hardwire Charger with DC cable is the ideal solution for providing power to any GDS® vehicle solution. With the quick disconnect feature, easily connect any USB Type A charging cable. When it comes time to upgrade, avoid any rewiring by simply unplugging the power connector and attaching the new charger components.

Compatible Devices:
Any 5V device with a current requirement of 2.5A or less

Input Voltage
30V - 64V DC

Output Voltage
5-9VDC

Output Current
2.5A max

Input Connector
90° DC Plug

Input Cable Length
1.2 Meters including 2 Pole Flat Marine Connector

Output Cable Length
0.2 Meter

Operating Temperature
-10°C to +70°C

Storage Temperature
-40°C to +70°C

Compliance
Over Voltage Protection
Short Circuit Protection
Reverse Polarity Protection
RoHS Compliance
WEEE Compliance
SAE J-1113-5 Load Dump (Transient Voltage)
Moisture Resistant

Certifications
CE Certification
e-Mark Certification
RCM Certification
FCC Certification


Additional Information
*5V output is by way of USB 2.0 BC1.2 and DCP mode. 9V output is by way of AFC and QC 2.0.

Weight
177 grams (0.39 lbs.)

Warranty Status
3 year warranty
