RAM-B-176U RAM® Motorcycle Fork Stem Double Ball Mount
Features
* Designed to fit into the cylindrical bore wall of fork stems
* Included B size Diamond Base incorporates 2 Hole AMPs pattern that will match many RAM cradsles for smaller devices
* RAM® double socket arm with ball and socket technology allows for near-infinite adjustability
* Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments
* Backed by a lifetime warranty
The RAM-B-176U consists of a fork stem motorcycle base, double socket arm and diamond base adaptor. The diamond adaptor base has a hole pattern that matches the industry standard AMPS hole pattern and will connect to a large variety of RAM Mount and third party cradles.
This part is designed to fit into the cylindrical bore wall of fork stems and will work with stems that measure from 12mm to 38mm (.5” to 1.49").
Specs & Features
Arm Dimensions:
Overall Length:
94mm (3.69")
Socket-To-Socket Length:
76mm (3")
Diamond Base Hole Pattern:
2-Hole AMPs:
1.912” (48.5mm)
Material:
Powder Coated Marine Grade Aluminium
Hardware Included
(1) Expansion Plug for 12mm - 38mm (.5" - 1.49") Fork Stem Holes
(1) M5 x 60mm Machine Screw
(1) Steel Washer Set
(1) Nut Pocket Washer Set
(1) Brass Nylock Nut
Weight Capacity
907 grams (2 lbs)
Ball Size:
1" Rubber Ball "B" Size
Weight:
272 grams (0.6 lbs.)
Components:
RAM-B-342U Fork Stem Base
RAM-B-201U RAM medium arm
RAM-B-238U Diamond Base
