RAP-B-379-HA1U RAM® Tough-Ball™ Mirror Base for Harley-Davidson Motorcycles
Features
* 1/4"-20 X 25mm threaded hole solution that replaces a standard Harley Davidson factory mirror with a RAM® fitting
* Base can be mounted above or below mirror holes
* Rubber ball dampens shock and vibration
* Included B size 1" RAM® rubber ball allows for connection to any B size RAM® double socket arm
* RAM® ball and socket technology allows for near-infinite adjustability
* Made of Powder-coated, marine-grade aluminium for durability and reliability in the most demanding marine environments
* Backed by a lifetime warranty
The RAP-B-379-HA1U consists of a 1/4"-20 X 25mm long thread, connected to a 1" diameter ball, female blind barrel nut and nylon washer and is perfect for replacing a factory mirror with a RAM® fitting.
Hardware Included
(1) 1/4"-20 x .87" Barrel Nut
(1) .77" Nylon Washer
Installation Instructions:
1. Locate fairing mirror holes.
2. Place the nylon washer over the barrel nut. Insert the barrel nut into the hole on the controls.
3. Screw the threaded ball into the barrel nut from the other side of the hole. Tighten with 5/8" and 1/2" wrench.
Compatible Harley-Davidson Motorcycles 2008 - current models WITHOUT hydraulic clutch including:
CVO Road Glide
CVO Ultra Classic Electra Glide
Electra Glide Classic
Electra Glide Standard
Road Glide
Road King
Road King Classic
Street Glide
Tri Glide Ultra Classic
Ultra Classic Electra Glide
Material:
High strength composite
Stainless steel threads
Ball Size:
1" Rubber Ball "B" Size
