RAM-B-202U-152 - Rectangular Base 38×50mm - B Series (1" Ball)

RAM-B-202U-152 RAM® Ball Base with 4-Hole Pattern - B Size

The RAM-B-202U-152 is a rectangular base plate with a 4-hole 25.4mm x 38.1mm (1" x 1.5") pattern and a B Size 1" rubber ball, ideal for mounting cup holders, fishfinders, and other accessories with a matching bolt pattern. This base requires an arm and cradle to form a complete mounting solution.

Key Features

• Rectangular plate with a 4-hole pattern, 25.4mm x 38.1mm (1" x 1.5") at each corner
• Included B Size 1" rubber ball connects to any B Size double socket arm
• Ball-and-socket technology allows near-infinite adjustability
• Powder-coated, marine-grade aluminium construction
• Backed by RAM Mounts' lifetime warranty

Dimensions & Specifications

• Hole pattern: 4-hole, 25.4mm x 38.1mm (1" x 1.5")
• Ball size: 1" rubber ball, B Size
• Material: Powder-coated marine-grade aluminium
• Weight: 64g (0.14 lbs)
• Weight capacity: 907g standard use, 454g heavy-duty use

FAQs

Is this a 4-hole AMPS pattern? No — the RAM-B-202U-152 uses a 25.4mm x 38.1mm (1" x 1.5") 4-hole pattern. For a 4-hole AMPS pattern, see the RAM-B-347U instead.

Is mounting hardware included? No, mounting hardware is not included with this base.
