RAM Motorcycle Brake/Clutch Reservoir Mount for Garmin Zumo

RAM® Brake/Clutch Reservoir Mount for Garmin Zumo 400-660 (Short Arm)

This RAM combination handlebar and brake/clutch reservoir mount gives you flexible options for fitting a Garmin Zumo (or compatible GPS) to your motorcycle. Mount to either the brake/clutch reservoir or a round rail, with a short 1" double socket arm for a compact, low-profile setup and near-infinite viewing-angle adjustment.

Key Features

• Combination handlebar and brake/clutch reservoir base, with U-bolt hardware for either mounting method
• Short B size 1" double socket arm for a tight, low-profile mount
• 4-hole AMPS plate pattern for broad device compatibility
• Patented ball-and-socket design dampens shock and vibration to help protect your device
• Backed by a lifetime warranty

Works With

Mounts to the brake/clutch reservoir or any round rail from 12.7 to 31.7mm (0.5" to 1.25") in diameter. To confirm reservoir fit, check your clutch/brake reservoir hole spacing against the base: hole centres span a minimum of 23.9mm (0.94") to a maximum of 40.1mm (1.58").

Dimensions & Specifications

• Clamp range: 12.7 to 31.7mm (0.5" to 1.25") diameter
• Socket-to-socket length: 44.4mm (1.75")
• Hole pattern: 4-Hole AMPS, 29.9 x 37.9mm (1.181" x 1.496")
• Ball size: 1" rubber ball (B size, 25.4mm)

Hardware Included

• (2) M6 x 55mm hex bolts
• (2) 1/4-20 x 2" hex bolts
• (2) 1/4"-20 x 2.5" hex bolts
• (2) 1/2" spacers
• (2) 1/4" split lock washers
• (1) 1/4"-20 U-bolt for 0.5" - 1" rails
• (1) 1/4"-20 U-bolt for 1" - 1.25" rails
• (2) 1/4"-20 Nylock nuts
• (2) rubber caps
• (1) U-bolt spacer

Compatible Devices

Garmin

• GPSMAP 276Cx
• zumo 390LM
• zumo 396 LMT-S
• zumo 400, 450, 500, 550, 590, 595LM, 660, 665
• zumo XT

Magellan

• TRX7
• TRX7 CS

RoadTech

• Zumo 590, 660, 665

TomTom

• Rider 2
• Urban Rider

Trail Tech

• Voyager Pro
