RAM-B-252-A-326U - EZY-Mount Quick Release Mount - 11mm Bolt Head Base - Short Arm

RAM-B-252-A-326U RAM® EZY-Mount™ Quick Release Mount with 11mm Bolt Head Base

The RAM-B-252-A-326U is a bolt-on motorcycle mount with RAM's EZY-Mount™ quick release, so your device cradle unclips in seconds. It combines the RAM-B-252U 11mm bolt head ball base, a short B Size double socket arm and the RAP-326U EZY-Mount™ adapter kit.

Key Features

• Bolt-on base: 57.2 x 22.2mm (2.25" x 0.875") plate with an 11mm hole; attaches to many motorcycle mirror mounts and, with a washer, many handlebar pinch bolts (base is 5mm thick)
• Short arm: B Size double socket arm, 44.5mm (1.75") socket to socket
• Quick release: the EZY-Mount™ halves snap together; push back the release tab to lift the cradle off
• Adjustable: 1" B Size rubber ball and socket system for near-infinite positioning

What's Included

• RAM-B-252U 11mm bolt head ball base
• RAM-B-201U-A short double socket arm
• RAP-326U EZY-Mount™ quick release adapter kit

Works With

Any RAM® cradle with the 2-hole AMPS pattern. Running more than one device? Add a RAP-326FU female adapter to each extra cradle. Bike has 9mm mirror bolts? See the RAM-B-272U angled 9mm base.

Dimensions & Specifications

• Base plate: 57.2 x 22.2mm (2.25" x 0.875"), 5mm thick, 11mm hole
• Arm: 44.5mm (1.75") socket to socket
• Ball size: B Size, 25.4mm (1")
• Weight capacity: 907g (2 lb) standard use, 454g (1 lb) heavy-duty use
• Materials: marine-grade aluminium, high-strength composite
• Weight: 191g (0.42 lb)
• Hardware: assembly hardware included
