RAP-B-326MU - EZY-Mount Quick Release Male Adapter - B Series (1" Ball) - Composite

RAP-B-326MU RAM® EZY-Mount™ Male Quick Release Ball Adapter, B Size

The RAP-B-326MU is the male half of the RAM® EZY-Mount™ quick release system, with a 1" B Size rubber ball built in. Click it into a female EZY-Mount™ adapter fitted to your cradle, drop the ball into any B Size double socket arm, and the cradle lifts on and off without touching the arm.

Key Features

• Quick release: snaps into a female EZY-Mount™ adapter; push back the release tab to remove
• B Size ball: 25.4mm (1") rubber ball fits any B Size RAM® double socket arm for near-infinite adjustment
• Load rating: 907g (2 lb) standard use, 454g (1 lb) heavy-duty use
• Lightweight: high-strength composite, 41g (0.09 lb)

Works With

Fit the RAP-326FU EZY-Mount™ Quick Release Female Adapter to any RAM® cradle with the 2-hole AMPS pattern, then click this adapter into it. Together they replace a fixed ball base like the RAP-B-238U, so you can take the cradle (and device) with you and leave the arm in place.

The system works either way round. To put the female clip on the arm side instead, see the RAP-B-326FU female adapter with built-in 1" ball.

Dimensions & Specifications

• Ball size: B Size, 25.4mm (1")
• Connection: EZY-Mount™ male quick release clip
• Weight capacity: 907g (2 lb) standard use, 454g (1 lb) heavy-duty use
• Material: high-strength composite
• Weight: 41g (0.09 lb)
• Packaging: poly bag

FAQs

What do I need to attach this to my cradle?

A female EZY-Mount™ adapter such as the RAP-326FU, which screws to your cradle's 2-hole AMPS pattern and comes with the fixing hardware.
